- Type Of Bath : Electrically Heated Immerssion Heater.
- Max Working Temperature :- 99 Degree C
- Continous Working Temperature :- 95 Degree C
- Capacity : 1 Sample At A Time.
- Heater : Ss Tubular Immerssion Heater
- Accuracy : +/- 3 Degree C 7) Readability : +/- 0.5 Degree C
- Temperature Controller : By Energy Regulator Which Will Turn On & Off Heater As Time Switch.
- Input Power Supply : 230 V Ac, 50 Hz, 1 Phase With 6 Amp Current Rating.
- Heating Load : 1 Kw .
- Stirrer : Manual Stirrer With Stirrer Blade For Maintaining Uniformity Throughout Chamber.
- Top Lid Made Of Stainless Steel With Provision Of Mounting Of One Thermometer.
- Control Panel/Display : Energy Regulator/ Heater Indicator/ Kettle Plug For Heater Connection.
- Construction : Double Walled Construction , Thermally Insulated With Inside Body Made Of Stainless Steel Outside Gi./ Powder Coated External Surface For Esthatic Appearance.
- What is redwood Viscometer?
The Redwood viscometer is an instrument used to measure the viscosity of a liquid. There are two types of Redwood viscometers: Redwood No. 1 and Redwood No. 2, each designed for different viscosity ranges.
- Difference between Redwood Viscometer No. 1 or Redwood Viscometer No. 2
The Redwood viscometer No. 1 is used for determining the oils having redwood viscosity up to 2000 secs. More than 2000 sec viscosity oil will be tested in Redwood viscometer No. 2.
- Purpose of the Redwood Viscometer ?
- Purpose: Designed for measuring the viscosity of lighter oils and fluids.
- Viscosity Range: Typically used for liquids with kinematic viscosities in the range of 1 to 2000 Redwood seconds (RS).
- Operation: The instrument consists of an oil cup, a heating bath, and a standardized orifice at the bottom. The oil cup is filled with the test fluid, which is then allowed to flow through the orifice. The time it takes for a specified volume of the liquid to pass through the orifice is measured.
- Units: The viscosity is expressed in Redwood seconds, which is the time in seconds for 50 mL of liquid to flow out through the orifice.
- Procedure for Using Redwood Viscometer No. 1
- Preparation: Ensure the viscometer is clean and free from any residues.
- Filling: Fill the oil cup with the sample liquid up to the specified level.
- Temperature Control: If the test requires a specific temperature, use the heating bath to maintain the required temperature of the sample.
- Flow Measurement: Open the orifice and start the timer simultaneously. Measure the time taken for 50 mL of the liquid to flow out.
- Calculation: The time recorded is the kinematic viscosity of the liquid expressed in Redwood seconds.
- Applications of the Redwood viscometer
- Commonly used in the petroleum industry to measure the viscosity of oils and lubricants.
- Helps in determining the quality and performance characteristics of oils.
- How to Convert Redwood viscosity to Kinematic viscosity ?
- Hamco will provide chart for calculating redwood viscosity to kinematic viscosity.
- Hamco also provide you the formula for calculating the kinematic viscosity of the oil deriving from its redwood viscosity.
- Why Hamco ?
- Hamco is leading Redwood viscometer manufacturer in india.
- Hamco has vast experience as Redwood viscometer No. 1 manufacturer and Redwood viscometer No 2 manufacturer and Redwood viscometer No. 1 & 2 manufacturer in india.
- Ss Lid Cover –1 No (Cat No Hamco 33ac1)
- Thermometer Collar — 1 No (Cat No Hamco 33ac2)
- Ball Lock – 1 No. (Cat No Hamco 33ac3)
- Glass Redwood Cup — 1 No. (Cat No Hamco 33ac4)
- Thermometer Ip 8c With Cal Cert – 1 No. (Cat No Hamco33ac4)
- Thermometer Ip 9c With Cal Cert – 1 No.(Cat No Hamco33ac5)
- Thermometer Ip 10c With Cal Cert – 1 No. (Cat No Hamco33ac6)
- Digital Stopwatch – 1 No (Cat No Hamco33ac7)
Spares Required For 5 Year Trouble Free Operation :
- Ss Immerssion Heater 1 No.(Cat No Hamco33s1)
- Glass Redwood Cup 1 No. (Cat No Hamco 33ac4)
- Thermometer Ip 8c With Cal Cert – 1 No. (Cat No Hamco33ac4)
- Thermometer Ip 9c With Cal Cert – 1 No.(Cat No Hamco33ac5)
- Thermometer Ip 10c With Cal Cert – 1 No. (Cat No Hamco33ac6)
- Digital Stopwatch – 1 No (Cat No Hamco33ac7)
Electrical Requirement :
- 220-240v, 50/60hz, Single Phase, 6.0a
- Or 115v, 50/60hz, Single Phase, 12.0a
Dimension :
- Ixwxh,In.(Cm) 9”X9”X18” (23x23x46)
- Net Weight: 12 Lbs (5.5kg)
Shipping Information
- Shipping Weight: 26.4 Lbs (12kg)
- Dimensions: 2.2 Cu. Ft.
Ordering Information
| CATALOGUE NO | PRODUCT DESCRIPTION | ELECTRICAL REQUIREMENT |
|---|---|---|
| Hamco 33rd2-A | Redwood Viscometer No.1 With Energy Regulator With Hand Stirrer | 220-240v, 50/60hz, 6.0 Amp |
| Hamco 33rd2-A-Exp | Redwood Viscometer No.1 With Energy Regulator With Hand Stirrer | 115v, 50/60hz, 12.0 Amp |
Optional Accessory Ordering Information :
| CATALOGUE NO | PRODUCT DESCRIPTION |
|---|---|
| Hamco 33ac1 | Ss Lid Cover |
| Hamco 33ac2 | Thermometer Collar |
| Hamco 33ac3 | Ball Lock |
| Hamco 33ac4 | Glass Redwood Cup |
| Hamco 33ac5 | Thermometer Ip 8c |
| Hamco 33ac6 | Thermometer Ip 9c |
| Hamco 33ac7 | Thermometer Ip 10c |
| Hamco 33ac8 | Digital Stopwatch |
Spares Ordering Information :
| CATALOGUE NO | PRODUCT DESCRIPTION |
|---|---|
| Hamco 33s1 | Ss Immerssion Heater |
Preinstallation Requisite ( At Buyer’s Scope)
- Distilled Water – 6 Ltr.
- Sample 200ml
- Washing Solvent.
